The eMabler platform defines various socket states to describe the real-time condition and behavior of a charging station. These states help operators and users understand the charging process and diagnose issues effectively. Below is a breakdown of each state:
State Descriptions
|
State |
Description |
|---|---|
|
Available |
The charger socket is idle and ready for use. No vehicle is connected, and the unit is fully operational and online. |
|
Preparing |
A vehicle is connected to the socket, but authorization has not been completed. Charging has not yet begun. |
|
Charging |
Active energy transfer is in progress. The vehicle is receiving charge. |
|
Suspended (CHARGER) |
The charger has temporarily paused charging, often due to load management (e.g., current falls below 6A). Charging can resume automatically when conditions allow. |
|
Suspended (CAR) |
The vehicle has paused the charging process (e.g., due to a full battery or a scheduled delay). The connection remains active, and charging may resume later. |
|
Finishing |
The charging session has ended (e.g., remotely stopped), but the vehicle is still connected to the charger. |
|
Reserved |
The socket is reserved for a future session. If charging does not start within a specified time (typically 15–30 minutes), the reservation is cleared automatically. |
|
Booting |
The charger is starting up. This is a system-generated transitional state. |
|
Error |
A fault has occurred at the charger, preventing normal operation. |
|
Offline |
The charger has lost connectivity to the backend. No operations are possible during this state. |
|
Unavailable |
The socket is intentionally disabled (e.g., for maintenance). Charging cannot be initiated. |
|
Info |
Informational state—not an actual status the socket stays in, but used for reporting diagnostic or status messages. |
Charger Socket State Flow
The diagram visually represents how the charger transitions between states depending on vehicle actions, user commands, or backend control. For instance:
-
A charger moves from Available → Preparing → Charging when a vehicle plugs in and authentication succeeds.
-
During a charging session, it may temporarily go into SuspendedCHARGER or SuspendedCAR, depending on the situation.
-
After charging ends, it may enter Finishing until the cable is unplugged.
-
At any point, external events (errors, disconnections, reservations) may lead to states like Error, Offline, or Reserved.
This flow ensures transparency in charger behavior and simplifies issue tracking for operators.
